LOINC Code Lookup API: Search Lab Tests and Build FHIR Observations

If your application touches lab results, it speaks LOINC. Every glucose level, every CBC, every culture result that moves between systems carries a LOINC code to say what was measured. It's the Observation.code half of the FHIR lab story — the other half being the result value and its units.

Working with LOINC directly is its own project. Regenstrief ships it as a set of CSV tables you have to download, accept a license for, parse, and reload a few times a year. This tutorial shows how to look up, search, and batch-process LOINC codes with FHIRfly's API and TypeScript SDK — and how to turn a lookup into a FHIR Observation.

What Makes LOINC Different

Unlike ICD-10 or NDC, a LOINC code isn't a flat label — it's a coordinate in a six-axis model. Each code is defined by its parts:

This is why "glucose" alone isn't enough — glucose in blood, in serum/plasma, in urine, and after a glucose challenge are all distinct codes. The parts are what let you disambiguate, and FHIRfly returns them as structured fields you can filter and read directly.

Setup

npm install @fhirfly-io/terminology

import { Fhirfly } from "@fhirfly-io/terminology";

const fhirfly = new Fhirfly({ apiKey: process.env.FHIRFLY_API_KEY! });

Free tier includes 10,000 requests/month — get your key here.

Look Up a Single Code

The most common operation: you have a LOINC code and need the name, parts, and units.

const result = await fhirfly.loinc.lookup("2345-7", { shape: "standard" });

console.log(result.data.code);
// "2345-7"

console.log(result.data.display_name);
// "Glucose, Blood"

console.log(result.data.long_name);
// "Glucose [Mass/volume] in Serum or Plasma"

console.log(result.data.parts.system);
// "Ser/Plas"

console.log(result.data.units.example_ucum_units);
// "mg/dL"

console.log(result.data.order_obs);
// "Both"  — orderable AND reportable

The order_obs field is worth noting: it tells you whether a code is meant to be ordered (Order), reported as a result (Observation), or Both. Use it to keep order-entry pick-lists separate from result-display logic.

Response Shapes

FHIR-Ready Coding

Every response includes a pre-built FHIR coding:

const result = await fhirfly.loinc.lookup("718-7", { shape: "standard" });

console.log(result.data.fhir_coding);
// {
//   system: "http://loinc.org",
//   code: "718-7",
//   display: "Hemoglobin, Blood"
// }

Drop this straight into an Observation.code — more on that below.

Search by Term, Component, and Specimen

Most LOINC work starts from a description, not a code. Search accepts a free-text q plus structured filters that map to the six axes.

const results = await fhirfly.loinc.search({ q: "glucose" }, { limit: 5 });

console.log(`${results.total} codes match "glucose"`);
// 976 codes match "glucose"

for (const code of results.items) {
  console.log(`${code.code} — ${code.display_name} (${code.class})`);
}
// "51595-7 — Glucose, Stool (CHEM)"
// "2349-9 — Glucose, Urine (CHEM)"
// "18296-4 — Glucose after dose glucose, Blood (CHAL)"
// "47622-6 — Glucose before dose glucose, Blood (CHAL)"
// "2339-0 — Glucose, Blood (CHEM)"

Nearly a thousand hits for one analyte — exactly why the axis filters matter. Narrow by specimen system, LOINC class, or scale:

// Hemoglobin measured in blood
await fhirfly.loinc.search({ q: "hemoglobin", system: "Bld" });
// 55235-6 (gene panel), 717-9, 718-7, 59260-0, ...
// Note the top hit is a panel, not a plain measurement — add scale: "Qn" to drop it.

// Only quantitative chemistry tests on serum
await fhirfly.loinc.search({
  class: "CHEM",
  system: "Ser/Plas",
  scale: "Qn",
});

// Only orderable codes (for an order-entry picker)
await fhirfly.loinc.search({ q: "lipid panel", order_obs: "Order" });

// Sort alphabetically instead of by relevance
await fhirfly.loinc.search({ q: "creatinine" }, { sort: "name" });

Pagination

let page = 1;
let hasMore = true;

while (hasMore) {
  const results = await fhirfly.loinc.search(
    { class: "CHEM", scale: "Qn" },
    { limit: 50, page }
  );

  for (const code of results.items) {
    await indexCode(code);
  }

  hasMore = results.has_more;
  page++;
}

Build a FHIR Observation

This is where LOINC earns its keep. A lab result in FHIR is an Observation whose code is a LOINC coding and whose valueQuantity carries the number and UCUM unit. FHIRfly hands you both pieces — the coding and an example UCUM unit — from a single lookup:

async function buildGlucoseObservation(value: number, patientId: string) {
  const loinc = await fhirfly.loinc.lookup("2345-7", { shape: "standard" });

  return {
    resourceType: "Observation",
    status: "final",
    code: {
      coding: [loinc.data.fhir_coding], // { system: "http://loinc.org", code, display }
      text: loinc.data.display_name,
    },
    subject: { reference: `Patient/${patientId}` },
    valueQuantity: {
      value,
      unit: loinc.data.units.example_units ?? undefined,       // "mg/dL"
      system: "http://unitsofmeasure.org",
      code: loinc.data.units.example_ucum_units ?? undefined,  // "mg/dL"
    },
  };
}

const obs = await buildGlucoseObservation(99, "123");

The example_ucum_units field is the bridge to a valid UCUM-coded valueQuantity. It reflects how the test is typically reported — confirm against your own result units before relying on it for conversion, since some analytes are reported in more than one unit.

Batch Lookups

Enriching a result feed or a lab interface with hundreds of codes? Use the batch endpoint:

const response = await fhirfly.loinc.lookupMany(
  ["2345-7", "718-7", "2160-0", "0000-0"],
  { shape: "standard" }
);

for (const result of response.results) {
  if (result.status === "ok") {
    console.log(`${result.input}: ${result.data.display_name}`);
  } else {
    console.log(`${result.input}: ${result.status}`);
  }
}
// "2345-7: Glucose, Blood"
// "718-7: Hemoglobin, Blood"
// "2160-0: Creatinine, Blood"
// "0000-0: not_found"

Batch accepts up to 100 codes per request. Each result carries its own status, so an invalid or retired code returns not_found without failing the whole batch — handy for validating an incoming feed.

Provenance and Ranking (Full Shape)

The full shape adds fields built for auditing and for prioritizing the tests that actually matter:

const result = await fhirfly.loinc.lookup("2345-7", { shape: "full" });

console.log(result.data.consumer_name);
// "Glucose, Blood"  — patient-friendly label

console.log(result.data.ranks);
// { common_test_rank: 6, common_order_rank: 120 }

console.log(result.data.version);
// "2.82"  — the LOINC release this term came from

common_test_rank reflects how frequently a code appears in real lab data (lower = more common). Use it to push the everyday tests to the top of an autocomplete and bury the obscure ones.

A Licensing Note

LOINC is free to use, but it is not public domain — it ships under the Regenstrief LOINC license, which requires attribution. FHIRfly surfaces this in every response so you don't have to track it separately:

const result = await fhirfly.loinc.lookup("2345-7", { shape: "standard" });

console.log(result.meta.legal.license);
// "regenstrief_license"

console.log(result.meta.legal.attribution_required);
// true

If you display LOINC names to end users, include the standard attribution. The full shape returns the exact citation string and terms-of-use link to make that straightforward.

REST API (Without the SDK)

# Single lookup
curl -H "x-api-key: $FHIRFLY_API_KEY" \
  "https://api.fhirfly.io/v1/loinc/2345-7?shape=standard"

# Search
curl -H "x-api-key: $FHIRFLY_API_KEY" \
  "https://api.fhirfly.io/v1/loinc/search?q=glucose&system=Bld&limit=10"

# Batch
curl -X POST -H "x-api-key: $FHIRFLY_API_KEY" \
  -H "Content-Type: application/json" \
  -d '{"codes": ["2345-7", "718-7", "2160-0"]}' \
  "https://api.fhirfly.io/v1/loinc/_batch?shape=standard"

Common Use Cases

Key Takeaways

• Six-axis model — component, property, time, system, scale, method are returned as structured, filterable fields
• Axis filters — narrow a thousand "glucose" hits down to the right specimen and scale
• FHIR + UCUM ready — fhir_coding and example_ucum_units build a valid Observation in one call
• order_obs — separates orderable codes from reportable results
• Common-test ranks — surface the tests clinicians actually use
• Batch endpoint — up to 100 codes, per-code status
• Attribution built in — Regenstrief license info travels with every response

Next Steps

1. Get a free API key from the FHIRfly dashboard
2. Install the SDK: npm install @fhirfly-io/terminology
3. Search for the tests in your lab catalog and check their parts
4. Read the LOINC API docs for the complete parameter reference
